Stabilus 4B-002429 TRUNK LID LIFT SUPPORT, 16.46 INCH, 12-07 MERCEDES Pack of 2

Stabilus 4B-002429 TRUNK LID LIFT SUPPORT, 16.46 INCH, 12-07 MERCEDES Pack of 2

Stabilus 4B-002429 TRUNK LID LIFT SUPPORT, 16.46 INCH, 12-07 MERCEDES

A gas charged lift support with dynamic speed control.

Features:

For best results replace in pairs.
Based on the OE design to ensure proper fit form and function.
Easy to install and require no special tools.
Part coatings tested to automotive standards for corrosion resistance.
No bouncing or jerking during cycling.
Dynamic damping speed control creates a fluid opening motion.

Lift-O-Mat by Stabilus – Precision Control with Dynamic Damping. Lift-O-Mat with dynamic damping sets a new standard in controlled motion, delivering refined, adaptable performance preferred by leading automakers. This advanced lift support utilizes a longitudinal groove known as a velocity manifold pressed into the tube wall, allowing gas to flow around the piston with extension speed and damping engineered for this specific application. This superior damping technology delivers performance and precision that hydraulic systems cannot match. The groove profile is expertly crafted to gradually narrow toward the end of the stroke, ensuring a gentle, controlled stop with minimal impact. Built from high-quality materials and fine-tuned for smooth, reliable function, Lift-O-Mat offers OE performance and design across industries requiring precision control. Why Choose Lift-O-Mat with Dynamic Damping? Dynamic Damping Technology: Continuous gas flow controlled by custom groove geometry delivers superior motion control and precision. OE-Preferred Solution: The damping technology specified by leading automakers for refined, consistent performance. Superior Performance: Engineered to deliver performance and precision beyond what hydraulic damping systems can achieve. Choose Lift-O-Mat by Stabilus for a dynamic damping solution that delivers superior, engineered performance and a smooth, gentle stop every time.

Attributes:

End1 Mount Diameter	0.394 IN
Inner Shaft Diameter	8 MM
Extended Length	16.46 IN
Stroke Length	168 MM
Compressed Length	250 MM
Extended Length	418 MM
Maximum Force	110 LB
End2 Mount Diameter	0.394 IN
Compressed Length	9.84 IN
Stroke Length	6.62 IN
Cylinder Outside Diameter	0.866 IN
Inner Shaft Diameter	0.315 IN
End1 Mount Diameter	10.0 MM
End2 Mount Diameter	10.0 MM
Maximum Force	490 NW
3890	Nylon
3889	Nylon
Cylinder Outside Diameter	22 MM
Mounting Hardware Included	No
End 1 Type	Ball Socket
End 2 Type	Ball Socket
Type	GAS

Vehicle Applications:

Make	Model	Years
Mercedes-Benz	SL500	2009 to 2012
Mercedes-Benz	SL550	2007 to 2012
Mercedes-Benz	SL600	2007 to 2012
Mercedes-Benz	SL63 AMG	2009 to 2012
Mercedes-Benz	SL65 AMG	2007 to 2011
