Stabilus 4B-063361 LIFTGATE LIFT SUPPORT, 17.13 INCH, 06-02 ACURA Pack of 2
Stabilus 4B-063361 LIFTGATE LIFT SUPPORT, 17.13 INCH, 06-02 ACURA
A hydraulically dampened gas charged lift support.
Features:
- Based on the OE design to ensure proper fit form and function.
- Patented Labyrinth Piston provides clog free and smooth operation during opening and closing.
- Clog free design prevents binding due to contamination.
- For best results replace in pairs.
- Part coatings tested to automotive standards for corrosion resistance.
- Easy to install and require no special tools.
Lift-O-Mat by Stabilus – Precision Motion with Controlled Damping. Lift-O-Mat with hydraulic damping provides proven, reliable performance using an innovative oil channeling system and patented labyrinth piston design. Finely tuned for each application with customized oil viscosities and piston configurations, this proven damping technology delivers the smooth, controlled motion engineered for this application. Engineered with high-quality materials and a precision seal-guide system, Lift-O-Mat withstands demanding applications across automotive, furniture, and ergonomic equipment industries with durability and reliable operation. Why Choose Lift-O-Mat with Hydraulic Damping? Proven Damping Technology: Custom-tuned oil viscosities and labyrinth piston designs ensure consistent motion control. High-Quality Build: High-grade materials and proprietary seal-guide system deliver performance and durability. Application-Specific Engineering: Every Lift-O-Mat is designed to meet exact application requirements. Choose Lift-O-Mat by Stabilus for hydraulic damping that delivers refined, controlled motion you can trust.
Attributes:
| Stroke Length | 6.58 IN |
| Cylinder Outside Diameter | 0.866 IN |
| End1 Mount Diameter | 0.394 IN |
| Compressed Length | 268 MM |
| End2 Mount Diameter | 0.394 IN |
| End2 Mount Diameter | 10.0 MM |
| 3889 | Nylon |
| Maximum Force | 135 LB |
| Mounting Hardware Included | No |
| End 1 Type | Ball Socket |
| End1 Mount Diameter | 10.0 MM |
| Cylinder Outside Diameter | 22 MM |
| 3890 | Nylon |
| End 2 Type | Ball Socket |
| Type | GAS |
| Inner Shaft Diameter | 0.394 IN |
| Maximum Force | 600 NW |
| Extended Length | 435 MM |
| Stroke Length | 167 MM |
| Inner Shaft Diameter | 10 MM |
| Extended Length | 17.13 IN |
| Compressed Length | 10.55 IN |
Vehicle Applications:
| Make | Model | Years |
| Acura | RSX | 2002 to 2006 |
