Bilstein 24-197649 B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber

Bilstein 24-197649 B8 5100 (Ride Height Adjustable) – Suspension Shock Absorber

46mm Monotube Shock Absorber

Features:

Adjustable spring seat offers 0-2.75in of lift, depending on the application
Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
46mm monotube design ensures consistent, fade-free performance in all conditions

Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

Attributes:

Title	Bilstein Shock Absorbers
PartType	Shocks / Struts
Series	B8 5100 (Ride Height Adjustable)
Collapsed Length (IN)	11.19
Stroke/Travel Length (IN)	4.24
Stroke/Travel Length (mm)	107.7
Extended Length (MM)	392.0
Piston Diameter	46mm
Body Design	Snap Ring Grooved Body (Coilover)
Shaft Diameter	14mm
Boot Included	Black Bellows
Spring Seat Included	Yes
Extended Length (IN)	15.43
Reservoir	No
Upper Mount Type	Stem
Finish	Zinc Plated
Collapsed Length (MM)	284.2
Segment	Light Truck
Lower Mount Type	Eye 14.2mm
Internal Design	Monotube
Adjustable Damping	Non-Adjustable
