Bilstein 24-329200 B8 5100 (Ride Height Adjustable) – Suspension Shock Absorber Pack of 2

Bilstein 24-329200 B8 5100 (Ride Height Adjustable) – Suspension Shock Absorber Pack of 2

Bilstein 24-329200 B8 5100 (Ride Height Adjustable) – Suspension Shock Absorber

46mm Monotube Shock Absorber

Features:

  • Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
  • Adjustable spring seat offers 0-2.75in of lift, depending on the application
  • 46mm monotube design ensures consistent, fade-free performance in all conditions



Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting.  Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.



Attributes:

Shaft Diameter 14mm
Extended Length (IN) 20.22
PartType Shocks / Struts
Spring Seat Included Yes
Boot Included Black Bellows
Title Bilstein Shock Absorbers
Collapsed Length (MM) 404.0
Body Design Snap Ring Grooved Body (Coilover)
Internal Design Monotube
Extended Length (MM) 513.5
Series B8 5100 (Ride Height Adjustable)
Collapsed Length (IN) 15.91
Reservoir No
Upper Mount Type Stem
Finish Zinc Plated
Segment Light Truck
Lower Mount Type Eye 16.2mm
Piston Diameter 46mm
Adjustable Damping Non-Adjustable
Stroke/Travel Length (IN) 4.31
Stroke/Travel Length (mm) 109.5



Vehicle Applications:

Make Model Years
Toyota Sequoia 2023 to 2025
Toyota Tundra 2022 to 2025
Weight 0.5 kg
