Bilstein 25-291315 B8 8100 (Bypass) – Suspension Shock Absorber

£1,388.95 Inc VAT

- +

Bilstein 25-291315 B8 8100 (Bypass) – Suspension Shock Absorber

60mm Shock Absorber

Features:

  • Dual tube external bypass offers position sensitive damping with independent adjustment for rebound and compression
  • 60mm large bore hard anodized aluminum piston offers a greater range of damping control and delivers exceptional long-term durability
  • Incremental flow adjuster offers finite and incremental changes in damping force for precise adjustments



Bilstein B8 8100 (Bypass) is a direct fit, position sensitive, damper for light trucks and SUV’s. These motorsports inspired shock absorbers utilize a dual tube externally adjustable bypass design. B8 8100 (Bypass) feature “Incremental Flow” bypass adjusters, allowing for finite and incremental changes for rebound and compression. The shocks utilize a bottom hose, remote reservoir exit port, delivering increased compression control during the full cycle. The remote reservoir is supplied with a bolt-on aluminum anodized chassis mount for an easy fitment. BILSTEIN B8 8100 (Bypass) will maximize the driver experience, offering unparalleled ride comfort and incredible bottom out control.



Attributes:

Upper Mount Type Bar Pin
Shaft Diameter 18mm
Segment Light Truck
Lower Mount Type Eye 12.1mm
Piston Diameter 60mm
PartType Shocks / Struts
Finish EVO Grey
Series B8 8100 (Bypass)
Spring Seat Included No
Extended Length (IN) 27.83
Collapsed Length (IN) 17.17
Reservoir Yes
Adjustable Damping Double Adjustable Compression and Rebound with Click Adjuster Knobs
Extended Length (MM) 707.0
Internal Design Monotube
Body Design Bypass Body (Non-Coilover)
Collapsed Length (MM) 436.0
Title Bilstein Shock Absorbers
Boot Included No



Vehicle Applications:

Make Model Years
Jeep Wrangler JK 2018 to 2018
Jeep Wrangler 2007 to 2017
Weight 8.788 kg
