Bilstein 25-304916 B8 8100 - Suspension Shock Absorber

Bilstein 25-304916 B8 8100 – Suspension Shock Absorber

60mm Shock Absorber

Features:

Direct fit for an easy installation
60mm remote reservoir offers increased oil capacity for consistent performance over rough terrain
60mm large bore digressive piston offers a greater range of tunability and delivers exceptional comfort without sacrificing control

Bilstein B8 8100 reservoir shock absorbers are a large bore 2.65-in OD direct fit solution for lifted trucks and SUVs. Constructed from aerospace quality billet components, the large 2.65-in OD shock body shock body offers a higher oil volume capacity to control heat while tackling rough road surfaces over long distances. Each B8 8100 offers a unique remote or piggyback reservoir solution for an easy, hassle free installation. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. The large 60mm piston design offers more comfort and control in all driving conditions. The Bilstein B8 8100 will allow you to tame the terrain in comfort.

Attributes:

Shaft Diameter	18mm
Body Design	60mm ID Smooth Body (Non-Coilover)
Internal Design	Monotube
Extended Length (MM)	691.0
Upper Mount Type	Eye 12.8mm
Reservoir	Yes
Collapsed Length (IN)	17.38
Extended Length (IN)	27.20
PartType	Shocks / Struts
Finish	Zinc Plated
Collapsed Length (MM)	441.4
Title	Bilstein Shock Absorbers
Boot Included	No
Spring Seat Included	No
Series	B8 8100
Adjustable Damping	Non-Adjustable
Piston Diameter	60mm
Lower Mount Type	Eye 12.8mm
Segment	Light Truck
