Delphi TA3615 Steering Tie Rod End

Delphi TA3615 Steering Tie Rod End

Features:

Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
Delphi tie rods are fatigue tested to avoid failure
Delphi includes the necessary accessories for a complete job
Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics

Delphi’s OE safety technology is fitted to millions of vehicles worldwide and we apply Delphi’s OE expertise to our aftermarket steering portfolio. Delphi tests to the extreme for OE performance at every turn: our parts withstand temperatures below -40 degrees C and over 120 degrees C and are exposed to 720 hours of salt spray. Delphi’s extensive dimensional and material analysis ensures the very best compatibility between the OE and aftermarket part.

Attributes:

Length – Stud Centre to End	202.50 MM
Pre-greased	Yes
Grease Fitting Included	No
Dust Boot Included	Yes
Type	Bent
Mounting Hardware Included	Yes
Grade Type	Standard Replacement
Housing Material	Steel
Adjustable	No
Greaseable	No
Boot Colour	Black
Bearing Material	Plastic
End 1 Thread Direction	Clockwise (Right)
End 2 Thread Direction	Clockwise (Right)
Head Drive Type	Hex
662	0.488 IN
627	1.59 LB
36	21.00 MM
36	0.830 IN
Position(s)	Right Outer
Length – Stud Centre to End	7.972 IN
Height	102.10 MM
Width	44 MM
Stud Length	12.40 MM
Stud Length	0.488 IN
Length	221.50 MM
662	12.40 MM
881	Threaded
9090	Chloroprene Rubber (CR)
1786	0.488 IN
1786	12.40 MM
Color	Black
End 1 Gender	Female
End 2 Gender	Male
9091	Steel
Finish	Painted
