Delphi TA5236 Steering Tie Rod End

Delphi TA5236 Steering Tie Rod End

Features:

Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
Delphi tie rods are fatigue tested to avoid failure
Delphi includes the necessary accessories for a complete job

Delphi’s OE safety technology is fitted to millions of vehicles worldwide and we apply Delphi’s OE expertise to our aftermarket steering portfolio. Delphi tests to the extreme for OE performance at every turn: our parts withstand temperatures below -40 degrees C and over 120 degrees C and are exposed to 720 hours of salt spray. Delphi’s extensive dimensional and material analysis ensures the very best compatibility between the OE and aftermarket part.

Attributes:

Grease Fitting Included	Yes
End 2 Thread Direction	Clockwise (Right)
End 1 Thread Direction	Clockwise (Right)
Bearing Material	Plastic
Length – Stud Centre to End	290.00 MM
Length – Stud Centre to End	11.417 IN
Height	85.00 MM
Width	45 MM
Stud Length	14.40 MM
Stud Length	0.567 IN
Length	312.00 MM
Greaseable	Yes
Adjustable	No
Position(s)	Inner
881	Threaded
9090	Rubber
9091	Steel
Housing Material	Steel
Grade Type	Standard Replacement
Mounting Hardware Included	Yes
Type	Straight
Dust Boot Included	Yes
Pre-greased	Yes
End 2 Gender	Male
End 1 Gender	Male
Color	Black
1786	0.567 IN
1786	14.40 MM
36	0.776 IN
36	19.70 MM
627	1.35 LB
662	0.567 IN
662	14.40 MM

Vehicle Applications:

Make	Model	Years
American Motors	AMX	1968 to 1980
American Motors	Ambassador	1970 to 1974
American Motors	American	1964 to 1968
American Motors	Concord	1978 to 1983
American Motors	Gremlin	1970 to 1978
American Motors	Hornet	1970 to 1977
American Motors	Javelin	1968 to 1974
American Motors	Matador	1971 to 1978
American Motors	Rambler	1969 to 1969
American Motors	Rebel	1970 to 1970
American Motors	Rogue	1966 to 1966
American Motors	Spirit	1979 to 1983
