Delphi TC2229 Suspension Control Arm and Ball Joint Assembly

Delphi TC2229 Suspension Control Arm and Ball Joint Assembly

Features:

Control arms utilize robot welding for consistent performance and quality
Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specfications
Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics

Delphi’s OE safety technology is fitted to millions of vehicles worldwide and we apply Delphi’s OE expertise to our aftermarket steering portfolio. Delphi tests to the extreme for OE performance at every turn: our parts withstand temperatures below -40 degrees C and over 120 degrees C and are exposed to 720 hours of salt spray. Delphi’s extensive dimensional and material analysis ensures the very best compatibility between the OE and aftermarket part.

Attributes:

Boot Material	Chloroprene Rubber (CR)
Finish	Painted
Pre-greased	Yes
Bushings Included	Yes
Dust Boot Included	Yes
Ball Joint Stud Type	Threaded
Material	Steel
Mounting Hardware Included	Yes
Adjustable	No
Greaseable	No
Finish	Black
Boot Colour	Black
Bearing Material	Plastic
Bushing Type	Rubber
6529	Power
Position(s)	Front Left Lower Rearward
2384	Yes
2386	Casting/Forged
Length	400.00 MM
Length	15.748 IN
Mounting Hole Diameter	14.20 MM
Mounting Hole Diameter	0.559 IN
4887	60.00 MM
4887	2.362 IN
4890	80.00 MM
4890	3.150 IN
4241	Yes
Grade Type	Premium
Mounting Hole Quantity	1
9090	Chloroprene Rubber (CR)
Bushing Colour	Black
Thread Direction	Clockwise (Right)
