Delphi TC6203 Suspension Stabilizer Bar Link Kit

Delphi TC6203 Suspension Stabilizer Bar Link Kit

Features:

Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
Delphi machines to micron tolerances to guarantee durability and smooth joint operation
Sway bar links manufactured with ultrasonic molding to help prevent future weld breakage
Delphi sway bar links are fatigue tested to avoid failure

Delphi’s OE safety technology is fitted to millions of vehicles worldwide and we apply Delphi’s OE expertise to our aftermarket steering portfolio. Delphi tests to the extreme for OE performance at every turn: our parts withstand temperatures below -40 degrees C and over 120 degrees C and are exposed to 720 hours of salt spray. Delphi’s extensive dimensional and material analysis ensures the very best compatibility between the OE and aftermarket part.

Attributes:

End 2 Type	Bushing
2981	SW18
2385	No
Sleeve Length	32.5 MM
Bolt Length	2.93 IN
Bolt Length	74.5 MM
Bushing Inside Diameter	0.67 IN
Bushing Inside Diameter	17.0 MM
Pre-greased	No
2397	17.0 MM
2397	0.67 IN
627	1.1 LB
Position(s)	Front Left
9296	Yes
Bushings Included	Yes
Bushing Outside Diameter	1.57 IN
Bushing Outside Diameter	40.0 MM
Length	2.93 IN
Length	74.5 MM
Sleeve Length	1.28 IN
Grade Type	Standard Replacement
Bushing Type	PU
Greaseable	No
Bolts Included	Yes
Washers Included	Yes
Dust Boot Included	No
Bushing Colour	Blue
End 1 Type	Bushing

Vehicle Applications:

Make	Model	Years
Ford	Excursion	2001 to 2005
Ford	Expedition	1997 to 2002
Ford	F-150 Heritage	2004 to 2004
Ford	F-150	1997 to 2003
Ford	F-250 HD	1997 to 1997
Ford	F-250 Super Duty	2001 to 2004
Ford	F-250	1997 to 1999
Ford	F-350 Super Duty	2001 to 2004
Lincoln	Blackwood	2002 to 2002
Lincoln	Navigator	1998 to 2002
