Delphi TC6861 Suspension Control Arm and Ball Joint Assembly

Delphi TC6861 Suspension Control Arm and Ball Joint Assembly

Features:

Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
Control arms utilize robot welding for consistent performance and quality
Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specfications
Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation

Delphi’s OE safety technology is fitted to millions of vehicles worldwide and we apply Delphi’s OE expertise to our aftermarket steering portfolio. Delphi tests to the extreme for OE performance at every turn: our parts withstand temperatures below -40 degrees C and over 120 degrees C and are exposed to 720 hours of salt spray. Delphi’s extensive dimensional and material analysis ensures the very best compatibility between the OE and aftermarket part.

Attributes:

Dust Boot Included	Yes
Bushings Included	Yes
Mounting Hole Diameter	0.677 IN
Pre-greased	Yes
Bushing Inside Diameter	17.20 MM
Finish	Painted
Bushing Length	62.00 MM
Bushing Inside Diameter	0.677 IN
4241	Yes
2386	Stamped
Bushing Colour	Black
Bushing Length	2.441 IN
Mounting Hole Diameter	17.20 MM
4887	305.00 MM
4887	12.008 IN
2384	Yes
Position(s)	Front Left Upper
9532	7.835 IN
4890	86.50 MM
4890	3.406 IN
Length	323.00 MM
Thread Direction	Clockwise (Right)
9532	199.00 MM
Length	12.717 IN
9090	Chloroprene Rubber (CR)
6529	Power
Boot Colour	Black
Bearing Material	Plastic
Bushing Type	Rubber
Finish	Black
Greaseable	No
Adjustable	No
Boot Material	Chloroprene Rubber (CR)
Mounting Hole Quantity	2
Grade Type	Premium
Mounting Hardware Included	Yes
Material	Steel
Ball Joint Stud Type	Threaded
Attachment Type	Press In
