Dorman 527-415 Suspension Control Arm And Ball Joint Assembly

Dorman 527-415 Suspension Control Arm And Ball Joint Assembly

Features:

Durably designed – additional coatings offer long-lasting rust and corrosion resistance
Trustworthy replacement – this control arm and ball joint assembly directly replaces the original assembly on specific vehicle applications
Complete repair – each assembly includes pre-installed ball joint and bushings, saving time and labor

This suspension control arm and ball joint assembly is a direct replacement for the original equipment on specific vehicle applications. An industry-leading evaluation process ensures a smooth ride, directional stability and predictable dynamics.

Attributes:

Bushing Length	81.5 MM
Thread Pitch	2 mm MM
Boot Colour	Black
Bearing Material	Polymer
Pre-greased	Yes
Grease Fitting Included	No
Bushings Included	Yes
Dust Boot Included	Yes
Grade Type	Standard Replacement
Length	415.5 MM
Thread Diameter	16 mm MM
4890	35 MM
Package Contents	1 Nut
Package Contents	1 Control Arm
End 2 Thread Size	2 mm
Attachment Type	Press In
Ball Joint Stud Type	Threaded
Ball Joint Included	Yes
End 1 Thread Pitch	2 mm MM
End 2 Thread Size	16 mm
Attachments Included	Yes
Thread Size	2 mm
1260	No
Ball Joint Thread Diameter	16 mm MM
2334	No
Material	Steel
2386	Stamped
9532	520 MM
Length	415.5 MM
2827	No
4887	520 MM
4241	Yes
6529	Power
Ball Joint Installed	Yes
Thread Size	16 mm
Finish	Black
Thread Direction	Clockwise (Right)
Set	Yes
Mounting Hardware Included	Yes
Adjustable	No
Bushing Type	Rubber
662	21.2 MM
Bushing Colour	Black
End 1 Thread Diameter	16 mm MM
Greaseable	No
Suspension Grade Type	Standard Replacement
Bushing Inside Diameter	19 MM
Bushing Length	76 MM
Finish	Painted
Control Arm Type	Stamped
Mounting Hole Quantity	0

Vehicle Applications:

Make	Model	Position	Years	Notes
Cadillac	Escalade ESV	Front Left Lower	2021 to 2025
Cadillac	Escalade	Front Left Lower	2021 to 2025
Chevrolet	Silverado 1500 LTD	Front Left Lower	2022 to 2022
Chevrolet	Silverado 1500 Nueva	Front Left Lower	2022 to 2022
Chevrolet	Silverado 1500	Front Left Lower	2019 to 2025
Chevrolet	Suburban	Front Left Lower	2021 to 2025
Chevrolet	Tahoe	Front Left Lower	2021 to 2025
GMC	Sierra 1500 Limited	Front Left Lower	2022 to 2022
GMC	Sierra 1500	Front Left Lower	2019 to 2025
GMC	Yukon XL	Front Left Lower	2021 to 2025
GMC	Yukon	Front Left Lower	2021 to 2025
