Dorman 544-097 Steering Tie Rod End

Dorman 544-097 Steering Tie Rod End

Features:

Durably designed – factory-sealed and precision-forged housing resists future corrosion
Reliably engineered – built to decrease wear rate and ensure overall strength
Trustworthy quality – backed by team of professional engineers and quality control specialists in the United States

This steering tie rod end directly replaces the original equipment tie rod on specific vehicle applications. It has undergone an industry-leading evaluation process to ensure smooth, safe operation.

Attributes:

Package Contents	1 Tie Rod End
Tie Rod End Thread Diameter	16 mm MM
Thread Pitch	1.5 mm MM
Thread Pitch	1.5 mm MM
Outside Diameter	24.04 mm MM
End 2 Thread Diameter	12 mm MM
End 1 Thread Diameter	16 mm MM
Center Mount Stud Quantity	1 IN
Center Mount Hole Quantity	1 IN
662	13.5 MM
36	24.04 MM
Length	95.5 MM
Width	39 MM
Height	78.87 MM
End 1 Thread Direction	Clockwise (Right)
Dust Boot Included	Yes
End 2 Thread Direction	Clockwise (Right)
881	Taper
9090	Polychloroprene
9091	Steel
Ball Joint Included	Yes
Bolts Included	No
End 1 Attachment Type	Threaded
End 2 Attachment Type	Threaded
End 2 Type	Threaded
Material	Steel
Package Contents	1 Nut
Grade Type	Standard
Head Drive Type	Hex
Color	Black
Type	Bent
Mounting Hardware Included	Yes
Adjustable	Yes
Finish	Powder Coated
Housing Material	Steel
Bearing Material	Polymer
End 1 Gender	Female
End 2 Gender	Male
Pre-greased	Yes
Grease Fitting Included	No

Vehicle Applications:

Make	Model	Position	Years	Notes
Audi	A3 Quattro	Front Left Outer	2015 to 2020
Audi	A3 Sportback e-tron	Front Left Outer	2016 to 2018
Audi	A3	Front Left Outer	2015 to 2020
Audi	Q2 Quattro	Front Left Outer	2018 to 2020
Audi	Q2	Front Left Outer	2018 to 2023
Audi	Q3	Front Left Outer	2019 to 2025
Audi	S3	Front Left Outer	2014 to 2020
Seat	Ateca	Front Left Outer	2017 to 2023
Seat	Leon	Front Left Outer	2017 to 2023
Seat	Tarraco	Front Left Outer	2019 to 2022
Volkswagen	Arteon	Front Left Outer	2019 to 2023
Volkswagen	GTI	Front Left Outer	2015 to 2021
Volkswagen	Golf Alltrack	Front Left Outer	2017 to 2019
Volkswagen	Golf R	Front Left Outer	2015 to 2019
Volkswagen	Jetta	Front Left Outer	2019 to 2025
Volkswagen	Passat CC	Front Left Outer	2009 to 2012
Volkswagen	Passat	Front Left Outer	2006 to 2010
Volkswagen	Taos	Front Left Outer	2022 to 2025
Volkswagen	Tiguan	Front Left Outer	2018 to 2024
