Dorman 924-5821 Air Tank Assembly

Dorman 924-5821 Air Tank Assembly

Features:

Direct replacement – this air reservoir features the same port configuration and physical dimensions as the original tank
Quality construction – this tank is made with precise port locations and finished in a corrosion-resistant coating inside and outside
Validation tested – has been salt spray chamber tested internally and externally to meet or exceed industry standard for corrosion resistance
Excellent value – original equipment quality at a lower cost

Maintain the effectiveness of air-actuated braking and suspension systems by replacing a corroded or leaking air tank with a new reservoir. Designed to fit like the original equipment tank with same port configurations.

Attributes:

Thread Size	22 m
Thread Size	22 m
Thread Size	22 m
Thread Size	22 m
Thread Size	22 m
Thread Size	22 m
Port Thread Pitch	1.5 mm
Port Thread Pitch	1.5 mm
Port Thread Pitch	1.5 mm
Port Thread Diameter	1/4 in
Port Thread Diameter	M22
Port Thread Diameter	M22
Port Thread Diameter	M22
Port Quantity	4
Package Contents	1 Air Tank
3515	0.13 IN
Diameter (B)	9.8 in IN
Length (A)	29.5 in IN
Mounting Type	Bolt-On
Maximum Working Pressure	150 PSI PS
Mounting Bracket Thread Diameter	M10 MM
Mounting Bracket Thread Pitch	1.5 mm MM
Number of Chambers	1 IN
Mounting Type	Strap On
Air Tank Type	Tractor
Tank Chamber Quantity	1 IN
Diameter	10 IN
Length	29.5 IN
Volume	35 L
Material	Carbon Steel
Color	Black
Mounting Hardware Included	No
Mounting Hole Quantity	0
Capacity	35 Lt
Valve Included	No
Threaded Mounting Bracket Included	Yes
Thread Size	1/4 in
