Gates G209950420 GS Ferrule for 4-Spiral Hose (GlobalSpiral)

Gates G209950420 GS Ferrule for 4-Spiral Hose (GlobalSpiral)

Features:

â€œBite-the-wireâ€ crimp for improved coupling retention
Tested to an industry-leading 1,000,000 impulse cycles
+250 Deg. F temperature capability for longer assembly life
Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard

GlobalSpiral couplings are specially engineered to provide superior performance for extreme high-pressure, high-impulse spiral-wire hydraulic hose applications. They can be used with all Gates MegaSys four- and six-spiral wire hose up to 6,000 psi. When used with 2-wire ferrules, GlobalSpiral couplings can also be crimped on Gates wire-braid hoses. The innovative, two-piece, no-skive design reduces assembly time, labor, fabrication errors and contamination of the ï¬‚uid power system.

Attributes:

Industrial Description	20GS1F-4
Inside Diameter	31.8
Inside Diameter	1.25
Outside Diameter	61.5
9952	All Gates MegaSys Four and Six-Spiral Wire Hydraulic Hose Up to 8,000 psi
Coupling Description	GlobalSpiral GS Ferrule for 4-Spiral Hose
Length	2.67
Length	67.8
Outside Diameter	2.42
