Gates G258300608 Female British Standard Parallel Pipe O-Ring Swivel (MegaCrimp)
Features:
- Robust “bite-the-wire†crimp
- Popular thread styles also available with TuffCoat Xtreme plating for 583 percent better corrosion resistance than the SAE Standard
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
- Simplifies inventory management
- Tested to an industry-leading 1,000,000 impulse cycles
The patented “C†insert pre-assembled MegaCrimp coupling gives world-class, leak-proof performance. It is designed with a patented “C†insert attached to the ferrule that accommodates hose of different constructions and wall thicknesses. The insert’s design ensures crimping forces are evenly distributed to form a concentric seal. The “C†insert simplifies inventory requirements since one MegaCrimp coupling size can accommodate various hose outside diameters, on both one- and two-wire braid hydraulic hose. Includes O-ring sealing in flare.
Attributes:
9923 | 27 |
Termination | British |
9927 | On Female w/Inverted Nose Seat |
9929 | 17.9 |
Thread Size | 01/02/2014 |
Coupling Description | MegaCrimp Female British Standard Parallel Pipe O-Ring Swivel |
9934 | Straight |
Inside Diameter | 0.375 |
Seal Type | Mated Angle w/O-Ring |
Swivel | Yes |
Length | 2.15 |
9929 | 0.7 |
Gender | Female |
6665 | 30 |
Length | 54.7 |
Inside Diameter | 9.5 |
9952 | Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose |
Industrial Description | 6G-8FBSPORX |
