MSD-8363 Cadillac V8 Distributor w/Vacuum Advance

MSD-8363 Cadillac V8 Distributor w/Vacuum Advance

Fits 368, 425, 472 and 500 Cadillac V8. Must be used with an MSD 6, 7 or 8-series ignition. Includes vacuum advance.

Features:

• Supplied with an HEI style distributor cap and rotor (accepts Cap-A-Dapts)
• Special oil tract improves lubrication to the distributor and cam gear
• Easy-to-adjust mechanical advance with supplied springs and stop bushings
• Must be used with an MSD Ignition Control
• Designed for Cadillac 368, 425, 472 and 500 ci engines
• Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
• Polished steel shaft is QPQ coated and guided by a sealed ball bearing
• CARB E.O. Approved
• Vacuum advance canister for improved economy (can be locked out)
• Mechanical advance assembly can be locked out for crank trigger systems
• CNC machined billet aluminum housing and billet aluminum base

MSD’s race proven magnetic pickup supplies a trigger signal that is accurate to within one degree at any rpm. Mounted above this pickup is an adjustable mechanical advance and is supplied with different springs and stop bushings for a number of curves. For street cruising economy, as if there’s any such thing in a Caddy, there is a vacuum advance canister.

The Distributor begins life as a billet of 6061-T6 aluminum before being CNC-machined to precise dimensions. The sturdy, flex-free housing is fitted with a sealed ball-bearing and long sintered bushing for high-rpm accuracy.

Cadillac cruisers will be excited about this new Pro-Billet distributor for the 368, 425, 472 and 500 cubic inch engines.
