MSD-84697 Chevy V8 Crank Trigger Distributor

MSD-84697 Chevy V8 Crank Trigger Distributor

Low-profile racing distributor, must be used with an MSD 6, 7 or 8-series ignition and a crank trigger.

Features:

• Must be used with an MSD Crank Trigger and MSD Ignition Control
• Oversized polished steel shaft with a QPQ coating for friction reduction
• Supplied with large diameter HEI style distributor cap and rotor
• O-ring seals can be added to modified blocks to improve oil pressure control
• CNC machined billet aluminum housing and Dupont Rynite base
• Shaft is guided by a sealed ball bearing and an extra long sintered bushing
• Special oil tract improves lubrication to the distributor and cam gear
• Supplied with bronze gear
• Designed to fit low in the block to clear firewall and intake combinations

have been designed into these low-profile distributors. This includes a large diameter cap with wide spaced terminals and an injection molded Rynite rotor

with thick vanes to stir up the air inside the cap. The high dielectric Rynite base also prevents arcing to the billet housing.

transferring the high voltage of the MSD racing ignition to the spark plugs.

The high voltage carrying capabilities are the result of several features which

The unique design of these distributors fit tight intake systems while still

Attributes:

Vehicle Applications:
