Scott Drake SDK-339-2AL 2 Row Hi Po Aluminum Radiator

SDK-339-2AL Scott Drake 2 Row Hi Po Aluminum Radiator

1967-1969 Ford Mustang, Late Model 5.0, 302 & 351C 2 Row Hi Po Aluminum Radiator

Features:

2 rows of extra-large, 1-inch tubes for 4-row efficiency
Includes a transmission cooler
Made from high quality aluminum
Designed for 1967-1969 Mustang with a late model 5.0L, 302 or 351C engine swap

This brand-new, 2-row 20-inch radiator is made from high-quality aluminum. It features 2 rows of extra-large, 1-inch tubes for 4-row efficiency minus the added weight, weighing in at 5-7 fewer pounds. The original, stock radiators for 1967-1969 Mustangs had trouble distributing the hot water to the far-right side of the radiator. This radiator, however, is equipped with Scott Drake’s specially designed, extensively tested baffle, which works to dispense the flow of hot water throughout the radiator evenly. This radiator includes a transmission cooler. Its inlet diameter measures 1-1/2 inches and its outlet diameter measures 1-3/4 inches.

Atributes:

Core Row Quantity	2
Core Height	16.375
Category	Belts and Cooling
Warning	California Proposition 65
Transmission Oil Cooler Included	Yes
Transcooler Provision	Yes
Sub Category	Radiators, Coolers and Related Components
Brand	Scott Drake
ROWS	2
Row Quantity	2
Radiator Cap Included	No
Product Type	Radiator
part type	Radiator
Outlet Size	1-3/4 in.
Outlet Location	Driver
Outlet Diameter	1-3/4 in.
Mounting Type	Bracket Mount
Material	Aluminum
Inlet Location	Passenger
Inlet Diameter	1 1/2
Hose Location Outlet	Driver
Hose Location Inlet	Passenger
Finish	Natural
Emission Code	6
Fan Included	No
Down Flow Or Cross Flow Type	Down Flow
Core Width	20.250
