Stabilus 4B-028480 BACK GLASS LIFT SUPPORT, 17.48 INCH, 05-95 CHEVROLET Pack of 2
Stabilus 4B-028480 BACK GLASS LIFT SUPPORT, 17.48 INCH, 05-95 CHEVROLET
A hydraulically dampened gas charged lift support.
Features:
- Based on the OE design to ensure proper fit form and function.
- Easy to install and require no special tools.
- Part coatings tested to automotive standards for corrosion resistance.
- Clog free design prevents binding due to contamination.
- For best results replace in pairs.
- Patented Labyrinth Piston provides clog free and smooth operation during opening and closing.
Lift-O-Mat by Stabilus – Precision Motion with Controlled Damping. Lift-O-Mat with hydraulic damping provides proven, reliable performance using an innovative oil channeling system and patented labyrinth piston design. Finely tuned for each application with customized oil viscosities and piston configurations, this proven damping technology delivers the smooth, controlled motion engineered for this application. Engineered with high-quality materials and a precision seal-guide system, Lift-O-Mat withstands demanding applications across automotive, furniture, and ergonomic equipment industries with durability and reliable operation. Why Choose Lift-O-Mat with Hydraulic Damping? Proven Damping Technology: Custom-tuned oil viscosities and labyrinth piston designs ensure consistent motion control. High-Quality Build: High-grade materials and proprietary seal-guide system deliver performance and durability. Application-Specific Engineering: Every Lift-O-Mat is designed to meet exact application requirements. Choose Lift-O-Mat by Stabilus for hydraulic damping that delivers refined, controlled motion you can trust.
Attributes:
| Maximum Force | 150 NW |
| End2 Mount Diameter | 10.0 MM |
| Maximum Force | 34 LB |
| Stroke Length | 162.5 MM |
| 3889 | Nylon |
| Mounting Hardware Included | No |
| Compressed Length | 281.5 MM |
| Type | GAS |
| Inner Shaft Diameter | 8 MM |
| Extended Length | 17.48 IN |
| Compressed Length | 11.08 IN |
| Stroke Length | 6.4 IN |
| End2 Mount Diameter | 0.394 IN |
| Cylinder Outside Diameter | 18 MM |
| 3890 | Nylon |
| End1 Mount Diameter | 10.0 MM |
| Inner Shaft Diameter | 0.315 IN |
| End 2 Type | Ball Socket |
| End 1 Type | Ball Socket |
| Extended Length | 444 MM |
| Cylinder Outside Diameter | 0.709 IN |
| End1 Mount Diameter | 0.394 IN |
Vehicle Applications:
| Make | Model | Years |
| Chevrolet | Blazer | 1995 to 2005 |
| GMC | Jimmy | 1995 to 2001 |
