Vision 310-0269 Remanufactured Power Steering Rack and Pinion Unit

Vision 310-0269 Remanufactured Power Steering Rack and Pinion Unit

Premium-quality remanufactured power steering rack & pinion designed for dependability and reliability throughout the service life of the vehicle.

Premium-quality remanufactured power steering rack & pinion designed for dependability and reliability throughout the service life of the vehicle.

Attributes:

Input Shaft Length (In)	4.813 in
Input Shaft Length (mm)	122.238 mm
6512	3
Distance Between Mounting Holes (In)	16.125 in
Type	Hydraulic
Mounting Hole Quantity	4
Input Shaft Length (In)	4.813 in
Inner Tie Rod Length	9.313
Pressure Port Thread Size	M14X1.50
Return Port Thread Size	M16X1.50
Inner Tie Rod Thread Size	2.188
6512	3
Inner Tie Rod Length	9.313
Pressure Port Thread Size	M14X1.50
Return Port Thread Size	M16X1.50
Sensor Included	No
6510	No
Check Valve	No
Orientation (Center)	Not Applicable
9182	Yes
Bushings Included	Yes
New or Remanufactured	New
Hydraulic, Electric, or Manual Steering	Hydraulic
Sensor Included	No
6510	No
Check Valve	No
Mounting Hole Quantity	4
Orientation (Center)	Not Applicable
9182	Yes
Bushings Included	Yes
Prop 65 Y/N	Y
Inner Tie Rod Thread Size	2.188
Rack Length (mm)	1200.15 mm
Input Shaft Length (mm)	122.238 mm
Rack Length (In)	47.25 in
Input Shaft Diameter (mm)	17.38 mm
Distance Between Mounting Holes (In)	16.125 in
Input Shaft Diameter (In)	0.684 in
