Vision 7290-12 Remanufactured Alternator

Vision 7290-12 Remanufactured Alternator

Premium-quality remanufactured alternator designed for dependability and reliability throughout the service life of the vehicle.

Attributes:

Series	17SI
Pulley Included	Yes
Voltage (V)	12 VDC
Outside Pulley Diameter (mm)	59 mm
Amperage (A)	108 A
Decoupled Or Clutch Pulley	No
Cooling Method	Air
Brushless Design	No
AC Tap	No
Amperage Rating	108 68
Outside Pulley Diameter	59 MM
Voltage	12 2H
New or Remanufactured	Remanufactured
Voltage Regulator Type	Internal
Series	17SI
Rotation Direction	Clockwise
Pulley Type	Conventional
Pulley Included	Yes
Pulley Belt Type	V-belt
Polarity	Negative
Plug Clock Position	12
Outside Pulley Diameter (in)	2-5/16
One Wire Capable	No
OE Manufacturer	Delco/Delphi
Number Of Pulley Grooves	1
Fan Type	External
External Fan Included	Yes
Rotation	Clockwise
Fan	External
Regulator	Internal
Pulley	V-belt
Pulley Groove Quantity	1
New or Remanufactured	Remanufactured
External Fan Included	Yes
Decoupled Or Clutch Pulley	No
9037	No
8122	No
229	No
Polarity	Negative
OE Manufacturer	Delco/Delphi
Pulley Type	Conventional
Cooling Method	Air
184	12
Outside Pulley Diameter (in)	2-5/16

Vehicle Applications:

Make	Model	Years
Buick	Century	1984 to 1985
Buick	Electra	1985 to 1985
Buick	Somerset Regal	1985 to 1985
Chevrolet	C10	1984 to 1984
Chevrolet	C20	1984 to 1984
Chevrolet	Celebrity	1984 to 1985
Chevrolet	Corvette	1984 to 1984
Chevrolet	G10	1984 to 1984
Chevrolet	G20	1984 to 1984
Chevrolet	G30	1984 to 1984
Chevrolet	Impala	1984 to 1984
Chevrolet	K10	1984 to 1984
GMC	C1500	1984 to 1984
GMC	C2500	1984 to 1984
GMC	G1500	1984 to 1984
GMC	G2500	1984 to 1984
GMC	G3500	1984 to 1984
GMC	K1500	1984 to 1984
Oldsmobile	98	1985 to 1985
Oldsmobile	Cutlass Ciera	1984 to 1985
Pontiac	6000	1984 to 1985
Pontiac	Grand Am	1985 to 1985
