Vision 8306 Remanufactured Alternator

Vision 8306 Remanufactured Alternator

Premium-quality remanufactured alternator designed for dependability and reliability throughout the service life of the vehicle.

Attributes:

OE Manufacturer	Ford
Fan Type	Internal
Plug Clock Position	3
Polarity	Negative
Pulley Belt Type	Serpentine
Pulley Included	Yes
Pulley Type	Conventional
Rotation Direction	Clockwise
Series	6G
Voltage Regulator Type	Internal
New or Remanufactured	Remanufactured
9037	No
Decoupled Or Clutch Pulley	No
8122	No
New or Remanufactured	Remanufactured
Number Of Pulley Grooves	8
One Wire Capable	No
Outside Pulley Diameter (in)	2-7/8
Pulley Groove Quantity	8
Rotation	Clockwise
Fan	Internal
Regulator	Internal
Pulley	Serpentine
Pulley Included	Yes
Amperage Rating	110 68
Outside Pulley Diameter	73 MM
Voltage	12 2H
AC Tap	No
229	No
Polarity	Negative
OE Manufacturer	Ford
Pulley Type	Conventional
Cooling Method	Air
Series	6G
184	3
Outside Pulley Diameter (in)	2-7/8
Brushless Design	No
Cooling Method	Air
Decoupled Or Clutch Pulley	No
Amperage (A)	110 A
Outside Pulley Diameter (mm)	73 mm
Voltage (V)	12 VDC

Vehicle Applications:

Make	Model	Years
Ford	E-350 Club Wagon	2004 to 2005
Ford	E-350 Super Duty	2004 to 2005
Ford	Excursion	2003 to 2005
Ford	F-250 Super Duty	2003 to 2005
Ford	F-350 Super Duty	2003 to 2005
